32944 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 16-22AWG #4 CRIMP
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.2728
≥1 USD $0.2728
≥10 USD $0.2508
≥100 USD $0.24992
≥500 USD $0.24464
≥1000 USD $0.209088
≥3000 USD $0.188179
Inventory: 18609
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 14 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)

Physical

Contact Material Copper
Mount Stud
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)

Technical

Packaging Bulk
Published 2004
Series Plasti-Grip
Feature Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Red
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Contact Finish Tin
Voltage - Rated AC 600V
Wire Gauge 16-22 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 22 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.080 ~ 0.125 (2.03mm ~ 3.18mm)
Insulation Insulated
Terminal Type Circular
Wire/Cable Diameter 3.18 mm
Stud/Tab Size 4 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 2.84 mm
Number of Holes 1
Stud Size M2.5

Dimensions

Length 17.37mm
Thickness 0.031 0.79mm
Length - Overall 0.684 17.37mm
Width - Outer Edges 0.218 5.54mm
Material Thickness 790μm
Tongue Thickness 840μm

Compliance

REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
