RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 10-12AWG #8 CRIMP
PDF
/
Buying Options
Total Price: USD $5.5
Unit Price: USD $5.502317
≥1 USD $5.502317
≥10 USD $5.190868
≥100 USD $4.897044
≥500 USD $4.619855
≥1000 USD $4.358347
Inventory: 9549
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 1.02mm
Material Thickness 1.07mm
Width - Outer Edges 0.312 7.92mm
Length - Overall 0.974 24.74mm
Thickness 0.040 1.02mm
Length 24.74mm
Technical
Stud Size M4
Number of Holes 1
Stud Diameter 4.34 mm
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 8 Stud
Wire Cross Section 6.64 mm2
Terminal Type Circular
Insulation Non-Insulated
Insulation Diameter 0.150 ~ 0.230 (3.81mm ~ 5.84mm)
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 10 AWG
ELV Compliant
Wire Gauge 10-12 AWG
Contact Finish Tin
HTS Code 8536.90.40.00
Gender Female
Color Yellow
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Serrated Termination
Series Diamond Grip
Published 1997
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 16 Weeks
