RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 16-22AWG #2 CRIMP
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5368
≥1 USD $0.5368
≥10 USD $0.5192
≥100 USD $0.419144
≥500 USD $0.325274
≥1000 USD $0.2838
≥3000 USD $0.270186
Inventory: 1223
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Material Copper
Contact Plating Tin
Mount Stud
Mounting Type Free Hanging (In-Line)
Material - Insulation Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2008
Series PIDG
Feature Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Red
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Depth 4.62mm
Voltage - Rated AC 300V
Wire Gauge 16-22 AWG
ELV Compliant
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 22 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.080 ~ 0.125 (2.03mm ~ 3.18mm)
Insulation Insulated
Terminal Type Circular
Wire/Cable Diameter 3.18 mm
Stud/Tab Size 2 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 2.36 mm
Number of Holes 1
Stud Size M2
Dimensions
Length 16.99mm
Thickness 0.031 0.79mm
Length - Overall 0.669 16.99mm
Width - Outer Edges 0.182 4.62mm
Tongue Thickness 790μm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Not Applicable
