323818 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 14-16AWG #10
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.012
≥1 USD $1.012
≥10 USD $0.94688
≥100 USD $0.814704
≥500 USD $0.642937
≥1000 USD $0.581284
≥3000 USD $0.54501
Inventory: 358
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant

Dimensions

Tongue Thickness 780μm
Width - Outer Edges 0.375 9.53mm
Length - Overall 0.906 23.01mm
Thickness 0.033 0.84mm
Length 23.01mm

Technical

Number of Holes 1
Stud Diameter 5 mm
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 10 Stud
Wire Cross Section 2 mm2
Wire/Cable Diameter 3.81 mm
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.150 (3.81mm)
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 14 AWG
Plating Tin
ELV Compliant
Wire Gauge 14-16 AWG
Voltage - Rated AC 300V
HTS Code 8536.90.40.00
Gender Female
Color Blue
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Offset Holes
Series PIDG
Published 2008
Packaging Bulk

Physical

Material - Insulation Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 16 Weeks
