RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 10-12AWG #10
PDF
/
Buying Options
Total Price: USD $9.83
Unit Price: USD $9.8296
≥1 USD $9.8296
≥10 USD $8.89064
≥100 USD $8.65568
≥500 USD $8.32656
≥1000 USD $7.71496
≥3000 USD $7.667898
Inventory: 695
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Nickel
Contact Plating Unplated
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2003
Series Diamond Grip, Strato-Therm
Feature High Temperature, Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Max Operating Temperature 649°C
Color Orange
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Depth 9.53mm
Wire Gauge 10-12 AWG
ELV Compliant
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.150 ~ 0.230 (3.81mm ~ 5.84mm)
Insulation Non-Insulated
Terminal Type Circular
Wire/Cable Diameter 5.842 mm
Wire Cross Section 6.64 mm2
Stud/Tab Size 10 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 5 mm
Number of Holes 1
Dimensions
Length 25.6mm
Thickness 0.040 1.02mm
Length - Overall 1.008 25.60mm
Width - Outer Edges 0.375 9.53mm
Tongue Thickness 1.0668mm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
Alternative Model
