RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 6AWG #10 CRIMP
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.1088
≥1 USD $1.1088
≥10 USD $1.01552
≥100 USD $0.9856
≥500 USD $0.975568
≥1000 USD $0.905608
≥3000 USD $0.89056
Inventory: 1180
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 1.52mm
Width - Outer Edges 0.468 11.89mm
Diameter - Inside 5.89 mm
Length - Overall 1.168 29.67mm
Thickness 0.057 1.45mm
Plating Thickness 7.62μm
Length 29.67mm
Technical
Number of Holes 1
Stud Diameter 5 mm
Terminal Gender FEMALE
Insulated Wire Support No
Stud/Tab Size 10 Stud
Terminal Type Circular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
ELV Compliant
Wire Gauge 6 AWG
Depth 11.89mm
Orientation Straight
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Brazed Seam, Serrated Termination
Series Solistrand, Strato-Therm
Published 1997
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Contact Plating Nickel
Contact Material Copper
