RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminals N/I-RING 08AWG #1/4 M6+
PDF
/
Buying Options
Total Price: USD $2.56
Unit Price: USD $2.5608
≥1 USD $2.5608
≥10 USD $2.28096
≥100 USD $2.269344
≥500 USD $2.246112
≥1000 USD $2.024968
≥3000 USD $2.013299
Inventory: 353
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 1.2954mm
Width - Outer Edges 0.469 11.91mm
Diameter - Inside 4.37 mm
Length - Overall 0.933 23.70mm
Thickness 0.048 1.22mm
Plating Thickness 7.62μm
Length 23.7mm
Technical
Stud Size M6
Number of Holes 1
Stud Diameter 6.731 mm
Heavy Duty No
Stud/Tab Size 1/4 Stud
Terminal Type Circular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 8 AWG
Wire Gauge 8 AWG
Contact Finish Nickel
Depth 11.91mm
Orientation Straight
HTS Code 8536.90.40.00
Gender Female
Color Silver
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Brazed Seam, Serrated Termination
Series Solistrand, Strato-Therm
Published 2008
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 9 Weeks
