323151 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 16-22AWG #6 CRIMP
PDF
/
Buying Options
Total Price: USD $1.06
Unit Price: USD $1.060905
≥1 USD $1.060905
≥10 USD $1.009286
≥100 USD $0.979379
≥500 USD $0.938723
Inventory: 30164
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant

Dimensions

Tongue Thickness 780μm
Width - Outer Edges 0.218 5.54mm
Length - Overall 0.645 16.38mm
Thickness 0.031 0.79mm
Length 16.38046mm

Technical

Stud Size M3.5
Number of Holes 1
Stud Diameter 3.68 mm
Terminal Gender FEMALE
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 6 Stud
Wire/Cable Diameter 2.79 mm
Terminal Type Circular
Insulation Non-Insulated
Insulation Diameter 0.051 ~ 0.110 (1.30mm ~ 2.79mm)
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 22 AWG
ELV Compliant
Wire Gauge 16-22 AWG
Contact Finish Nickel
Orientation Straight
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Serrated Termination
Series Diamond Grip, Strato-Therm
Published 1997
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 15 Weeks
