Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 10-12AWG #1/4
PDF
/
Buying Options
Total Price: USD $1.1
Unit Price: USD $1.1
≥1 USD $1.1
≥10 USD $1.02608
≥100 USD $0.988064
≥500 USD $0.978736
≥1000 USD $0.883168
≥3000 USD $0.854515
Inventory: 1185
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Copper
Mount Stud
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 1997
Series Solistrand, Strato-Therm
Feature Brazed Seam, Serrated Termination
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Max Operating Temperature 340°C
Color Silver
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Depth 13.49mm
Contact Finish Nickel
Wire Gauge 10-12 AWG
ELV Compliant
Wire Gauge (Max) 10 AWG
Wire Gauge (Min) 12 AWG
Wire/Cable Gauge 10 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Circular
Wire/Cable Diameter 3.3 mm
Wire Cross Section 6.64 mm2
Stud/Tab Size 1/4 Stud
Heavy Duty No
Stud Diameter 6.731 mm
Number of Holes 1
Stud Size M6
Dimensions
Length 19.43mm
Plating Thickness 7.62μm
Thickness 0.039 0.99mm
Length - Overall 1.004 25.50mm
Diameter - Inside 3.28 mm
Width - Outer Edges 0.531 13.49mm
Tongue Thickness 1.0668mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Not Applicable
