RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 14-16AWG #8 CRIMP
PDF
/
Buying Options
Total Price: USD $0.71
Unit Price: USD $0.7128
≥1 USD $0.7128
≥10 USD $0.67672
≥100 USD $0.557128
≥500 USD $0.437994
≥1000 USD $0.375417
≥3000 USD $0.368755
Inventory: 3968
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Tongue Thickness 840μm
Material Thickness 840μm
Width - Outer Edges 0.343 8.71mm
Diameter - Inside 2.16 mm
Length - Overall 0.636 16.15mm
Thickness 0.031 0.79mm
Plating Thickness 2.54μm
Length 16.15mm
Technical
Stud Size M4
Number of Holes 2
Stud Diameter 4.34 mm
Heavy Duty No
Stud/Tab Size 8 Stud
Wire/Cable Diameter 2.1 mm
Terminal Type Circular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 14 AWG
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
ELV Compliant
Wire Gauge 14-16 AWG
Contact Finish Nickel
Depth 8.71mm
Orientation Straight
HTS Code 8536.90.40.00
Gender Female
Color Silver
Max Operating Temperature 340°C
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Brazed Seam, Serrated Termination
Series Solistrand, Strato-Therm
Published 1997
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 months ago)
Factory Lead Time 4 Weeks
