RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 14-16AWG #1/4
PDF
/
Buying Options
Total Price: USD $2.1
Unit Price: USD $2.1032
≥1 USD $2.1032
≥10 USD $1.87528
≥100 USD $1.694
≥500 USD $1.37045
≥1000 USD $1.208662
Inventory: 1522
Minimum: 1
-
+
Technical Details
Technical
ELV Compliant
Wire Gauge (Max) 14 AWG
Wire Gauge (Min) 16 AWG
Wire/Cable Gauge 14 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Circular
Wire/Cable Diameter 2.1 mm
Stud/Tab Size 1/4 Stud
Heavy Duty No
Terminal Gender FEMALE
Stud Diameter 6.731 mm
Number of Holes 2
Stud Size M6
Wire Gauge 14-16 AWG
Depth 11.89mm
Orientation Straight
HTS Code 8536.90.40.00
Color Orange
Max Operating Temperature 650°C
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Brazed Seam, High Temperature, Serrated Termination
Series Solistrand, Strato-Therm
Published 1997
Packaging Bulk
Dimensions
Length 21.722mm
Plating Thickness 2.54μm
Thickness 0.030 0.76mm
Length - Overall 0.855 21.72mm
Diameter - Inside 2.16 mm
Width - Outer Edges 0.468 11.89mm
Material Thickness 840μm
Tongue Thickness 840μm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Not Applicable
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Unplated
Contact Material Nickel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 24 Weeks
