322257 image
Favorite
RoHS
RoHS RoHS compliant
Package 300
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 300-350MCM #3/8
PDF
/
Inventory: 5951
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant

Dimensions

Tongue Thickness 3.56mm
Material Thickness 3.56mm
Width - Outer Edges 1.545 39.24mm
Diameter - Inside 20.8 mm
Length - Overall 2.671 67.84mm
Thickness 0.136 3.45mm
Plating Thickness 2.54μm
Length 67.84mm

Technical

Number of Holes 2
Stud Diameter 9.525 mm
Heavy Duty No
Stud/Tab Size 3/8 Stud
Terminal Type Circular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 8 AWG
Wire Gauge (Min) 300 AWG
Wire Gauge (Max) 350 AWG
ELV Compliant
Wire Gauge 300-350MCM (kcmil)
Contact Finish Tin
HTS Code 8536.90.40.00
Gender Female
Color Red
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Brazed Seam
Series Solistrand
Published 2003
Packaging Bulk

Physical

Package / Case 300
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 4 Weeks
