RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 4AWG #3/8 CRIMP
PDF
/
Buying Options
Total Price: USD $12.41
Unit Price: USD $12.408
≥1 USD $12.408
≥10 USD $12.15192
≥100 USD $10.14816
≥500 USD $8.726142
Inventory: 150
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2004
Series Solistrand
Feature Brazed Seam, Serrated Termination
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp, Flag
ECCN Code EAR99
HTS Code 8536.90.40.00
Depth 17.32mm
Wire Gauge 4 AWG
Wire/Cable Gauge 4 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Circular
Wire Cross Section 26.7 mm2
Stud/Tab Size 3/8 Stud
Heavy Duty No
Terminal Gender FEMALE
Stud Diameter 9.906 mm
Number of Holes 1
Dimensions
Length 32.46mm
Thickness 0.048 1.22mm
Length - Overall 1.278 32.46mm
Diameter - Inside 7.11 mm
Width - Outer Edges 0.682 17.32mm
Material Thickness 1.2954mm
Tongue Thickness 1.3mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
