RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 14-16AWG #10
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.012
≥1 USD $1.012
≥10 USD $0.94512
≥100 USD $0.909568
≥500 USD $0.900768
≥1000 USD $0.812944
≥3000 USD $0.786579
Inventory: 3711
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2005
Series PIDG
Feature Heavy Duty, Serrated Termination
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Yellow, Black Stripe
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Depth 8.71mm
Voltage - Rated AC 300V
Wire Gauge 14-16 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Sealable No
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.150 ~ 0.230 (3.81mm ~ 5.84mm)
Insulation Insulated
Terminal Type Circular
Wire/Cable Diameter 5.842 mm
Wire Cross Section 2.62 mm2
Stud/Tab Size 10 Stud
Heavy Duty Yes
Stud Diameter 4.82 mm
Number of Holes 1
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Tongue Thickness 1.27mm
Width - Outer Edges 0.343 8.71mm
Length - Overall 1.046 26.57mm
Thickness 0.048 1.22mm
Length 26.5684mm
