RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 10-12AWG #5/16
PDF
/
Buying Options
Total Price: USD $0.56
Unit Price: USD $0.5632
≥1 USD $0.5632
≥10 USD $0.54824
≥100 USD $0.391424
≥500 USD $0.343077
≥1000 USD $0.299332
≥3000 USD $0.28497
Inventory: 2321
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Material Copper
Contact Plating Tin
Mount Stud
Mounting Type Free Hanging (In-Line)
Material - Insulation Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 1997
Series PIDG
Feature Serrated Termination
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Yellow
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Depth 13.49mm
Voltage - Rated AC 300V
Wire Gauge 10-12 AWG
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Wire/Cable Gauge -10 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.150 ~ 0.230 (3.81mm ~ 5.84mm)
Insulation Insulated
Terminal Type Circular
Wire/Cable Diameter 5.842 mm
Stud/Tab Size 5/16 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 7.9248 mm
Number of Holes 1
Stud Size M8
Dimensions
Length 33.5788mm
Thickness 0.040 1.02mm
Length - Overall 1.322 33.58mm
Width - Outer Edges 0.531 13.49mm
Tongue Thickness 1.0668mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
