31266 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 16-22AWG #10
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.307415
≥1 USD $0.307415
≥10 USD $0.251165
≥100 USD $0.22631
Inventory: 56
Minimum: 1
-
+

Technical Details

Technical

Number of Holes 1
Stud Diameter 5 mm
Heavy Duty No
Stud/Tab Size 10 Stud
Terminal Type Circular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 22 AWG
ELV Compliant
Wire Gauge 16-22 AWG
Depth 7.14mm
Orientation Straight
HTS Code 8536.90.40.00
Gender Female
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Serrated Termination
Series Budget
Published 1997
Packaging Bulk

Dimensions

Length 14.5796mm
Tongue Thickness 790μm
Material Thickness 790μm
Width - Outer Edges 0.281 7.14mm
Diameter - Inside 1.65 mm
Length - Overall 0.574 14.58mm
Thickness 0.031 0.79mm
Width 7.14mm

Physical

Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 8 Weeks

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC No SVHC
