RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 16-22AWG #8 CRIMP
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2112
≥1 USD $0.2112
≥10 USD $0.18304
≥100 USD $0.181984
≥500 USD $0.179696
≥1000 USD $0.166056
≥3000 USD $0.13647
Inventory: 17535
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 1997
Series Budget
Feature Serrated Termination
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Red
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Depth 7.14mm
Contact Finish Tin
Wire Gauge 16-22 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 16 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Circular
Stud/Tab Size 8 Stud
Heavy Duty No
Stud Diameter 4.34 mm
Number of Holes 1
Stud Size M4
Dimensions
Length 14.5796mm
Width 7.14mm
Thickness 0.031 0.79mm
Length - Overall 0.574 14.58mm
Diameter - Inside 1.65 mm
Width - Outer Edges 0.281 7.14mm
Material Thickness 790μm
Tongue Thickness 790μm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
