2178506-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 14-18AWG M3.5
PDF
/
Buying Options
Total Price: USD $0.1
Unit Price: USD $0.1045
≥1 USD $0.1045
≥10 USD $0.0855
≥100 USD $0.0836
≥500 USD $0.08075
≥1000 USD $0.0779
Inventory: 1005
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Brass
Mounting Type Free Hanging (In-Line)
Material Brass
Technical
Packaging Strip
Published 2011
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Contact Finish Tin
Wire Gauge 14-18 AWG
ELV Compliant
Plating Brass
Sealable No
Insulation Diameter 0.105 ~ 0.170 (2.67mm ~ 4.32mm)
Insulation Non-Insulated
Terminal Type Circular
Wire/Cable Diameter 4.318 mm
Stud/Tab Size M3.5 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 3.9 mm
Government Qualified No
Number of Holes 1
Stud Size M3.5
Dimensions
Length 16.75mm
Thickness 0.020 0.51mm
Length - Overall 0.659 16.74mm
Diameter - Inside 1.42 mm
Width - Outer Edges 0.295 7.49mm
Material Thickness 500μm
Tongue Thickness 500μm
Compliance
RoHS Status RoHS Compliant
