2-323914-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminals NYL-RING 24 YEL/BLU #10
PDF
/
Buying Options
Total Price: USD $1.29
Unit Price: USD $1.2936
≥1 USD $1.2936
≥10 USD $1.18624
≥100 USD $1.05776
≥500 USD $0.847361
≥1000 USD $0.759704
≥3000 USD $0.723254
Inventory: 3828
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 500μm
Width - Outer Edges 0.203 5.16mm
Length - Overall 0.691 17.55mm
Thickness 0.018 0.46mm
Length 16.4084mm
Technical
Stud Size M2.5
Number of Holes 1
Stud Diameter 3.0226 mm
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 4 Stud
Wire Cross Section 0.24 mm2
Wire/Cable Diameter 2.08 mm
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.031 ~ 0.055 (0.79mm ~ 1.40mm)
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 24 AWG
Plating Tin
ELV Compliant
Wire Gauge 24 AWG
Voltage - Rated AC 300V
Contact Finish Nickel
Depth 5.16mm
Voltage - Rated DC 300V
HTS Code 8536.90.40.00
Gender Female
Color Yellow, Blue Stripe
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Insulation Restriction, Serrated Termination
Series PIDG
Published 2008
Packaging Bulk
Physical
Material - Insulation Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Nickel, Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 30 Weeks
