2-322128-2
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 8AWG #10 CRIMP
PDF
/
Inventory: 7578
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status Non-RoHS Compliant
Dimensions
Width - Outer Edges 0.431 10.95mm
Length - Overall 1.562 39.67mm
Thickness 0.040 1.02mm
Width 10.95mm
Length 39.67mm
Technical
Stud Diameter 5 mm
Heavy Duty No
Stud/Tab Size 10 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.298 (7.57mm)
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 8 AWG
ELV Non-Compliant
Wire Gauge 8 AWG
Contact Finish Tin
HTS Code 8536.90.40.00
Gender Female
Color Red
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Serrated Termination
Series Ampli-Bond
Published 1997
Packaging Tape & Reel (TR)
Physical
Material - Insulation Vinyl
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 3 Weeks
