2-320631-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 14-16AWG #6 CRIMP
PDF
/
Buying Options
Total Price: USD $0.86
Unit Price: USD $0.8624
≥1 USD $0.8624
≥10 USD $0.82544
≥100 USD $0.789184
≥500 USD $0.778448
≥1000 USD $0.68024
≥3000 USD $0.65472
Inventory: 146
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 25 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Polyamide (PA), Nylon
Technical
Packaging Tape & Reel (TR)
Published 2006
Series PIDG
Feature Heavy Duty, Serrated Termination
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Yellow, Black Stripe
HTS Code 8536.90.40.00
Depth 7.14mm
Wire Gauge 14-16 AWG
ELV Compliant
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Sealable No
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Diameter 0.150 ~ 0.230 (3.81mm ~ 5.84mm)
Insulation Insulated
Terminal Type Circular
Wire/Cable Diameter 5.842 mm
Stud/Tab Size 6 Stud
Heavy Duty Yes
Terminal Gender FEMALE
Stud Diameter 3.5052 mm
Number of Holes 1
Stud Size M3.5
Dimensions
Length 24.2062mm
Thickness 0.048 1.22mm
Length - Overall 0.553 14.05mm
Width - Outer Edges 0.281 7.14mm
Tongue Thickness 1.27mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
