2-320572-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 20AWG #5/16 CRIMP
PDF
/
Buying Options
Total Price: USD $0.9
Unit Price: USD $0.8976
≥1 USD $0.8976
≥10 USD $0.85976
≥100 USD $0.822272
≥500 USD $0.810832
≥1000 USD $0.708576
≥3000 USD $0.68207
Inventory: 1130
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Copper
Mount Stud
Mounting Type Free Hanging (In-Line)
Material - Insulation Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2005
Series PIDG
Feature Insulation Restriction
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Red, Red Stripe
Gender Female
HTS Code 8536.90.40.00
Voltage - Rated DC 300V
Contact Finish Tin
Voltage - Rated AC 300V
Number of Contacts 1
Wire Gauge 20 AWG
ELV Compliant
Wire/Cable Gauge 20 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.046 ~ 0.110 (1.17mm ~ 2.79mm)
Insulation Insulated
Terminal Type Circular
Wire/Cable Diameter 2.79 mm
Wire Cross Section 0.6 mm2
Stud/Tab Size 5/16 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 7.9248 mm
Stud Size M8
Dimensions
Length 27.38mm
Thickness 0.031 0.79mm
Length - Overall 1.140 28.96mm
Width - Outer Edges 0.469 11.91mm
Tongue Thickness 840μm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Not Applicable
