RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Ring Tongue Terminal 13.5-17AWG 16mm 8mm Tin Strip
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.2552
≥1 USD $0.2552
≥10 USD $0.2244
≥100 USD $0.20372
≥500 USD $0.147004
≥1000 USD $0.130258
≥3000 USD $0.115368
Inventory: 10017
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 months ago)
Physical
Contact Material Copper
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2005
Series Solistrand
Feature Serrated Termination
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
HTS Code 8536.90.40.00
Depth 8mm
Wire Gauge 14-16 AWG
ELV Compliant
Plating Tin
Wire Gauge (Max) 17 AWG
Wire Gauge (Min) 5 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Circular
Wire Cross Section 2.5 mm2
Stud/Tab Size 8 Stud
Insulated Wire Support No
Terminal Gender FEMALE
Stud Diameter 4.3 mm
Number of Holes 1
Stud Size M4
Dimensions
Length 16.383mm
Thickness 0.031 0.79mm
Width - Outer Edges 0.315 8.00mm
Material Thickness 800μm
Tongue Thickness 800μm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
