RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Ring Tongue Terminal 10-12AWG 21.97mm 12.7mm Tin Loose Piece
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.396
≥1 USD $0.396
≥10 USD $0.3696
≥100 USD $0.36784
≥500 USD $0.358512
≥1000 USD $0.30756
≥3000 USD $0.278186
Inventory: 1857
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Lifecycle Status ACTIVE (Last Updated: 23 hours ago)
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Package / Case Metal
Technical
Packaging Bulk
Published 2004
Series Solistrand
Feature Brazed Seam, Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Gender Female
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Depth 12.7mm
Contact Finish Tin
Wire Gauge 10-12 AWG
ELV Compliant
Connector Support Type CONNECTOR ACCESSORY
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Insulation Non-Insulated
Terminal Type Circular
Stud/Tab Size M6 Stud
Heavy Duty No
Stud Diameter 6.25 mm
Number of Holes 1
Stud Size M6
Military Connector Accessory Name CHIMNEY
Dimensions
Length 21.971mm
Thickness 0.039 0.99mm
Length - Overall 0.865 21.97mm
Diameter - Inside 3.28 mm
Width - Outer Edges 0.500 12.70mm
Material Thickness 1mm
Tongue Thickness 1mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
