RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 2/0AWG CRIMP
PDF
/
Buying Options
Total Price: USD $7.04
Unit Price: USD $7.04
≥1 USD $7.04
≥10 USD $6.13184
≥100 USD $5.970624
≥500 USD $5.809232
≥1000 USD $5.45424
≥3000 USD $5.421926
Inventory: 53
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Package / Case Metal
Technical
Packaging Bulk
Published 2006
Series Solistrand
Feature Brazed Seam
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
HTS Code 8536.90.40.00
Depth 24.03mm
Contact Finish Tin
Wire Gauge 2/0 AWG
Wire/Cable Gauge 0 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Insulated
Terminal Type Circular
Wire Cross Section 70 mm2
Heavy Duty No
Stud Diameter 10.4902 mm
Number of Holes 1
Stud Size M10
Dimensions
Length 51.5112mm
Thickness 0.079 2.01mm
Length - Overall 2.000 50.80mm
Diameter - Inside 12.802 mm
Width - Outer Edges 0.925 23.50mm
Material Thickness 2mm
Tongue Thickness 2mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
