RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 20AWG #10 CRIMP
PDF
/
Buying Options
Total Price: USD $10.45
Unit Price: USD $10.453738
≥1 USD $10.453738
≥10 USD $9.862021
≥100 USD $9.303792
≥500 USD $8.777169
≥1000 USD $8.280338
Inventory: 5686
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 787μm
Material Thickness 787.4μm
Width - Outer Edges 0.312 7.92mm
Diameter - Inside 2.134 mm
Length - Overall 0.803 20.40mm
Thickness 0.031 0.79mm
Length 20.4mm
Technical
Stud Size M5
Number of Holes 1
Stud Diameter 5 mm
Terminal Gender FEMALE
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 10 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.045 ~ 0.080 (1.14mm ~ 2.03mm)
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 20 AWG
ELV Compliant
Wire Gauge 20 AWG
Voltage - Rated AC 300V
Depth 7.92mm
HTS Code 8536.90.40.00
Color Purple, Red Stripe
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Serrated Termination
Series PIDG, Strato-Therm
Published 2006
Packaging Bulk
Physical
Material - Insulation Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 45 Weeks
