RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 20AWG #8 CRIMP
PDF
/
Inventory: 901
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Width - Outer Edges 0.281 7.14mm
Length - Overall 0.787 20.00mm
Thickness 0.031 0.79mm
Length 19.9898mm
Technical
Stud Diameter 4.3 mm
Heavy Duty No
Stud/Tab Size 8 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.045 ~ 0.080 (1.14mm ~ 2.03mm)
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 20 AWG
ELV Compliant
Wire Gauge 20 AWG
Voltage - Rated AC 300V
Depth 7.14mm
HTS Code 8536.90.40.00
Color Gray
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Serrated Termination
Series PIDG, Strato-Therm
Published 1997
Packaging Bulk
Physical
Material - Insulation Polytetrafluoroethylene (PTFE)
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Nickel
Contact Material Copper
Supply Chain
Factory Lead Time 3 Weeks
