151382-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminals SHAKE PROOF RT 20-16 0.18 X .485 TPSTL
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.201352
≥1 USD $0.201352
≥10 USD $0.189951
≥100 USD $0.179195
≥500 USD $0.169054
≥1000 USD $0.159483
Inventory: 8271
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 510μm
Material Thickness 457.2μm
Width - Outer Edges 0.350 8.89mm
Diameter - Inside 1.14 mm
Length - Overall 0.675 17.15mm
Thickness 0.018 0.46mm
Length 17.145mm
Technical
Number of Holes 1
Stud Diameter 5 mm
Heavy Duty No
Insulated Wire Support Yes
Terminal Type Circular
Insulation Non-Insulated
Insulation Diameter 0.098 ~ 0.118 (2.50mm ~ 3.00mm)
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 15 AWG
ELV Compliant
Wire Gauge 16-20 AWG
Depth 8.89mm
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Inner Teeth
Published 2005
Packaging Reel
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Steel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 14 Weeks
