RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminal Ring Connector
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.6248
≥1 USD $0.6248
≥10 USD $0.60456
≥100 USD $0.602272
≥500 USD $0.581856
≥1000 USD $0.487872
≥3000 USD $0.457389
Inventory: 7252
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 800μm
Material Thickness 787.4μm
Width - Outer Edges 0.217 5.50mm
Diameter - Inside 3.25 mm
Length - Overall 0.807 20.50mm
Thickness 0.031 0.79mm
Plating Thickness 2.54μm
Length 20.5mm
Technical
Stud Size M2.5
Number of Holes 1
Government Qualified No
Stud Diameter 3.0226 mm
Heavy Duty No
Insulated Wire Support Yes
Terminal Type Flat Sided
Insulation Insulated
Insulation Diameter 3.2 mm
Sealable No
Body Plating Tin
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 22 AWG
Plating Tin
ELV Compliant
Wire Gauge 16-22 AWG
Contact Finish Tin
Depth 5.5mm
Gender Female
Color Red
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Serrated Termination
Series PIDG
Published 2005
Packaging Bulk
Physical
Body Material Copper
Material Nylon
Insulation Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Stud
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 31 Weeks
