2-34959-1
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminal Ring Connector
PDF
/
Inventory: 7630
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 840μm
Thickness 787.4μm
Plating Thickness 2.54μm
Length 23.368mm
Technical
Number of Holes 1
Stud Diameter 4.82 mm
Heavy Duty No
Insulated Wire Support Yes
Wire Cross Section 2.62 mm2
Wire/Cable Diameter 6.35 mm
Insulation Insulated
Insulation Diameter 6.35 mm
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 14 AWG
ELV Compliant
Voltage - Rated AC 600V
HTS Code 8536.90.40.00
Color Black
ECCN Code EAR99
Termination Circular
Pbfree Code yes
Packaging Tape & Reel (TR)
Physical
Insulation Material Vinyl
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
