2-34162-3
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminal Ring Connector
PDF
/
Inventory: 983
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Insulation Material Vinyl
Technical
Packaging Tape & Reel (TR)
Pbfree Code yes
Termination Circular
ECCN Code EAR99
Color Black
HTS Code 8536.90.40.00
Voltage - Rated AC 600V
ELV Compliant
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 4.9022 mm
Insulation Insulated
Wire/Cable Diameter 4.9 mm
Wire Cross Section 2.62 mm2
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 6.731 mm
Number of Holes 1
Stud Size M6
Dimensions
Length 27.686mm
Plating Thickness 2.54μm
Thickness 787.4μm
Material Thickness 787.4μm
Tongue Thickness 790μm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
