PV2-38R-XY
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Ring Tongue Terminal 2AWG 49.78mm 17.27mm Tin
PDF
/
Buying Options
Total Price: USD $5.3
Unit Price: USD $5.300559
≥1 USD $5.300559
≥10 USD $5.000528
≥100 USD $4.717479
≥500 USD $4.450456
≥1000 USD $4.198539
Inventory: 8357
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width - Outer Edges 0.680 17.27mm
Length - Overall 1.960 49.78mm
Thickness 0.060 1.52mm
Length 49.784mm
Technical
Stud/Tab Size 3/8 Stud
Terminal Type D-Shaped
Insulation Insulated
Insulation Diameter 0.560 (14.22mm)
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 2 AWG
Wire Gauge 2 AWG
Depth 17.27mm
HTS Code 8536.90.40.00
Color Red
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Brazed Seam
Series Pan-Term?
Published 2006
Packaging Bulk
Physical
Material - Insulation Vinyl
Weight 117.934016g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
