PV18-10RX-M
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 18-22AWG #10
PDF
/
Inventory: 9517
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width - Outer Edges 0.310 7.87mm
Length - Overall 0.960 24.38mm
Thickness 0.030 0.76mm
Width 7.87mm
Length 24.384mm
Technical
Stud/Tab Size 10 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.170 (4.32mm)
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge 18-22 AWG
Contact Finish Tin
Reach Compliance Code compliant
HTS Code 8536.90.40.00
Color Red
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Brazed Seam, Serrated Termination
Series Pan-Term?
Published 2001
Packaging Bulk
Physical
Material - Insulation Vinyl
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
