PV14-8R-L
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 14-16AWG #8 CRIMP
PDF
/
Inventory: 6381
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width - Outer Edges 0.310 7.87mm
Length - Overall 0.920 23.37mm
Thickness 0.032 0.81mm
Width 7.87mm
Length 23.368mm
Technical
Stud/Tab Size 8 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.170 (4.32mm)
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge 14-16 AWG
Contact Finish Tin
Color Blue
Termination Crimp
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Brazed Seam
Series Pan-Term?
Published 2002
Packaging Bulk
Physical
Material - Insulation Vinyl
Weight 56.699046g
Material Copper
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
