PV14-10R-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 14-16AWG #10
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.616
≥1 USD $0.616
≥10 USD $0.60016
≥100 USD $0.543224
≥500 USD $0.486077
≥1000 USD $0.457486
≥3000 USD $0.443186
Inventory: 484
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 1.134009g
Material - Insulation Vinyl
Technical
Packaging Bulk
Published 2002
Series Pan-Term?
Feature Brazed Seam
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp
ECCN Code EAR99
Color Blue
HTS Code 8536.90.40.00
Orientation Straight
Depth 7.9mm
Wire Gauge 14-16 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Wire/Cable Gauge -14 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.170 (4.32mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 10 Stud
Terminal Gender FEMALE
Dimensions
Length 23.368mm
Width 7.87mm
Thickness 0.032 0.81mm
Length - Overall 0.920 23.37mm
Width - Outer Edges 0.310 7.87mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Alternative Model
