PM2-3R-X

Panduit Corp
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description Terminals METRIC TERM RING NON-INS
PDF
/
Inventory: 5532
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width - Outer Edges 0.230 5.84mm
Length - Overall 0.620 15.75mm
Thickness 0.032 0.81mm
Length 15.748mm

Technical

Stud/Tab Size M3 Stud
Wire Cross Section 2.5 mm2
Terminal Type Circular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 14 AWG
Wire Gauge 14-16 AWG
Depth 5.84mm
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Brazed Seam, Serrated Termination
Series Pan-Term?
Published 2006
Packaging Bulk

Physical

Weight 4.535924g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
