PH10-38R-E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Ring Tongue Terminal 10-12AWG 30.48mm 14.99mm Tin
PDF
/
Buying Options
Total Price: USD $2.08
Unit Price: USD $2.0768
≥1 USD $2.0768
≥10 USD $2.02048
≥100 USD $1.96438
≥500 USD $1.90828
≥1000 USD $1.852224
≥3000 USD $1.79608
Inventory: 257
Minimum: 1
-
+
Technical Details
Technical
Color Yellow
HTS Code 8536.90.40.00
Depth 14.99mm
Wire Gauge 10-12 AWG
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.240 (6.10mm)
Insulation Insulated with Heat Shrink
Terminal Type Circular
Stud/Tab Size 3/8 Stud
Terminal Gender FEMALE
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Brazed Seam
Series Pan-Term?
Published 2011
Packaging Bulk
Dimensions
Length 30.48mm
Width 15mm
Length - Overall 1.200 30.48mm
Width - Outer Edges 0.590 14.99mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Physical
Material - Insulation Polyolefin
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
