P14-4R-M
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Ring Tongue Terminal 14-18AWG 15.8mm 6.4mm Tin Bulk
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.2552
≥1 USD $0.2552
≥10 USD $0.24816
≥100 USD $0.231792
≥500 USD $0.215239
≥1000 USD $0.204204
≥3000 USD $0.193169
Inventory: 781
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 752.963334g
Technical
Packaging Bulk
Published 2011
Series Pan-Term?
Feature Brazed Seam, Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp
ECCN Code EAR99
Color Blue
Gender Female
HTS Code 8536.90.40.00
Depth 6.4mm
Contact Finish Tin
Wire Gauge 14-18 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Circular
Stud/Tab Size 4 Stud
Dimensions
Diameter 4.06mm
Length 15.8mm
Width 6.35mm
Thickness 0.030 0.76mm
Length - Overall 0.620 15.75mm
Diameter - Inside 2.29 mm
Width - Outer Edges 0.250 6.35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
