0191930134
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Ring Tongue Terminal 10-12AWG 26.8mm 15.2mm Tin VersaKrimp? Loose Piece
PDF
/
Buying Options
Total Price: USD $0.5
Unit Price: USD $0.5016
≥1 USD $0.5016
≥10 USD $0.42416
≥100 USD $0.329824
≥500 USD $0.259116
≥1000 USD $0.235558
Inventory: 127
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width - Outer Edges 0.598 15.19mm
Length - Overall 1.056 26.82mm
Thickness 0.040 1.02mm
Technical
Stud/Tab Size 1/4 Stud
Wire Cross Section 5 mm2
Terminal Type Circular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge 10-12 AWG
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Brazed Seam
Series VersaKrimp
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
