0190750012
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Star Ring Tongue Terminal 18-22AWG 23.62mm 9.77mm Tin InsulKrimp? Tape
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.308
≥1 USD $0.308
≥10 USD $0.2508
≥100 USD $0.183832
Inventory: 4056
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Steel
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)
Technical
Packaging Tape & Reel (TR)
Series InsulKrimp
Feature Inner Teeth
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Red
HTS Code 8536.90.40.00
Contact Finish Electro-Tin
Wire Gauge 18-22 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.145 (3.68mm)
Insulation Insulated
Terminal Type Circular
Wire Cross Section 1.3 mm2
Stud/Tab Size 10 Stud
Dimensions
Thickness 0.050 1.27mm
Length - Overall 0.900 22.86mm
Width - Outer Edges 0.375 9.53mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
