0190740014

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description Star Ring Tongue Terminal 18-22AWG 17.78mm 9.77mm Tin Krimptite? Tape
PDF
/
Inventory: 6097
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width - Outer Edges 0.375 9.53mm
Length - Overall 0.674 17.12mm
Thickness 0.050 1.27mm
Length 17.1196mm

Technical

Stud/Tab Size 10 Stud
Wire Cross Section 1 mm2
Terminal Type Circular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Body Plating Tin
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge 18-22 AWG
Contact Finish Electro-Tin
Depth 9.77mm
HTS Code 8536.90.40.00
Gender Female
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Inner Teeth, Serrated Termination
Series Krimptite
Packaging Tape & Reel (TR)

Physical

Body Material Brass, Steel
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Steel

Supply Chain

Factory Lead Time 4 Weeks
