0190730077
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Ring Tongue Terminal 14-16AWG 27.36mm 12.12mm Electro-Tin Avikrimp? Tape Mounted
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.5808
≥1 USD $0.5808
≥10 USD $0.49192
≥100 USD $0.382624
Inventory: 9758
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width - Outer Edges 0.388 9.86mm
Length - Overall 1.077 27.36mm
Thickness 0.031 0.79mm
Technical
Stud/Tab Size 1/4 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.170 (4.32mm)
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge 14-16 AWG
Contact Finish Tin
Color Blue
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Serrated Termination
Series Avikrimp
Packaging Tape & Reel (TR)
Physical
Material - Insulation Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Contact Material Copper
Supply Chain
Factory Lead Time 5 Weeks
