0190710273
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Ring Tongue Terminal 2AWG 56.1mm 22.3mm Tin InsulKrimp? Loose Piece
PDF
/
Inventory: 3540
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width - Outer Edges 0.867 22.02mm
Length - Overall 2.234 56.74mm
Thickness 0.075 1.91mm
Length 56.7436mm
Technical
Stud/Tab Size 1/4 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.650 (16.51mm)
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 2 AWG
Wire Gauge 2 AWG
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Red
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Brazed Seam
Series InsulKrimp
Packaging Bulk
Physical
Material - Insulation Poly-Vinyl Chloride (PVC)
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 5 Weeks
