0190710247
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminal Ring Connector
PDF
/
Inventory: 3115
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Copper
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)
Technical
Packaging Tape & Reel (TR)
Series InsulKrimp
Feature Brazed Seam
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Yellow
Contact Finish Electro-Tin
Wire Gauge 4 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.515 (13.08mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 7/16 Stud
Dimensions
Thickness 0.067 1.70mm
Length - Overall 1.846 46.89mm
Width - Outer Edges 0.652 16.56mm
Compliance
RoHS Status ROHS3 Compliant
