0190710152
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Ring Tongue Terminal 8AWG 36.1mm 15.3mm Tin InsulKrimp? Mylar Tape
PDF
/
Buying Options
Total Price: USD $1.2
Unit Price: USD $1.1968
≥1 USD $1.1968
≥10 USD $0.9944
≥100 USD $0.828344
Inventory: 518
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)
Technical
Packaging Tape & Reel (TR)
Series InsulKrimp
Feature Brazed Seam
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Red
HTS Code 8536.90.40.00
Voltage - Rated DC 300V
Contact Finish Tin
Wire Gauge 8 AWG
Wire/Cable Gauge 8 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.330 (8.38mm)
Insulation Insulated
Terminal Type Circular
Wire Cross Section 10.5 mm2
Stud/Tab Size 3/8 Stud
Dimensions
Length 36.322mm
Thickness 0.045 1.14mm
Length - Overall 1.430 36.32mm
Width - Outer Edges 0.583 14.81mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
