0190700268
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminal Ring Connector
PDF
/
Inventory: 2008
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)
Technical
Packaging Bulk
Series InsulKrimp
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Blue
Gender Female
Contact Finish Electro-Tin
Wire Gauge 14-16 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Insulation Diameter 0.175 (4.45mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 1/4 Stud
Dimensions
Length 28.702mm
Thickness 6.35mm
Length - Overall 1.130 28.70mm
Width - Outer Edges 0.470 11.94mm
Compliance
RoHS Status ROHS3 Compliant
