0190700077

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description Terminal Ring Connector
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.414271
≥1 USD $0.414271
≥10 USD $0.39083
≥100 USD $0.3687
≥500 USD $0.347833
≥1000 USD $0.328144
Inventory: 980
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width - Outer Edges 0.470 11.94mm
Length - Overall 1.130 28.70mm
Thickness 6.35mm
Length 28.702mm

Technical

Stud/Tab Size 1/4 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.175 (4.45mm)
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge 14-16 AWG
Contact Finish Electro-Tin
Gender Female
Color Blue
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series InsulKrimp
Packaging Tape & Reel (TR)

Physical

Material - Insulation Poly-Vinyl Chloride (PVC)
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Factory Lead Time 10 Weeks
