0190670343
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
NylaKrimp ROHS3Compliant Insulated Brazed Seam Ring Terminal Connector 0.428 (10.87mm)
PDF
/
Inventory: 9646
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width - Outer Edges 0.480 12.19mm
Length - Overall 1.610 40.89mm
Thickness 0.050 1.27mm
Technical
Stud/Tab Size 1/4 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.428 (10.87mm)
Wire Gauge 6 AWG
Contact Finish Electro-Tin
Color Blue
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Brazed Seam
Series NylaKrimp
Packaging Bulk
Physical
Material - Insulation Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 15 Weeks
