0190670103

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description Terminal Ring Connector
PDF
/
Buying Options
Total Price: USD $2.82
Unit Price: USD $2.816
≥1 USD $2.816
≥10 USD $2.475264
≥100 USD $1.969
≥500 USD $1.631441
≥1000 USD $1.462674
Inventory: 16358
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width - Outer Edges 0.840 21.34mm
Length - Overall 2.628 66.75mm
Thickness 0.075 1.91mm
Length 66.7512mm

Technical

Stud/Tab Size 1/4 Stud
Terminal Type Flat Sided
Insulation Insulated
Insulation Diameter 0.680 (17.27mm)
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 1 AWG
Wire Gauge 1/0 AWG
Contact Finish Electro-Tin
Color Blue
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Brazed Seam
Series NylaKrimp
Packaging Bulk

Physical

Material - Insulation Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
