0190580119

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description Terminal Ring Connector
PDF
/
Inventory: 1765
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width - Outer Edges 0.592 15.04mm
Length - Overall 1.362 34.59mm
Thickness 0.050 1.27mm
Length 34.5948mm

Technical

Stud/Tab Size 3/8 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.225 (5.72mm)
Body Plating Tin
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge 14-16 AWG
Contact Finish Electro-Tin
Depth 15.2mm
Color Yellow
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Heavy Duty
Series Avikrimp
Packaging Tape & Reel (TR)

Physical

Body Material Copper
Material - Insulation Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Factory Lead Time 6 Weeks
